Description
The Stihl MSA 300 C-O is the most powerful chainsaw in the STIHL AP Battery System and is truly professional-grade.
The Stihl MSA 300 C-O sets the benchmark in performance as the most powerful battery chainsaw in the STIHL lineup. Certified by the American Green Zone Alliance (AGZA), this battery-saw offers various features to maximize performance and deliver optimal user comfort. Its lightweight design, rubberized soft-touch handle, and anti-vibration technology minimize fatigue. A genuinely professional-grade battery chainsaw, the Stihl MSA 300 C-O also features a lightweight magnesium motor housing that provides added durability to this powerful chainsaw. The electronic operating system, captive bar nut, and side-access chain tensioner simplify maintenance. The fleece air filter, mechanical and electronic chain brake, and oil sensor round out the features of this power-packed saw.
Features
- Electronic Operating System
- Low Oil Sensor
- STIHL Quickstop®
- IPX4 Rating
Model Features
- Electronic Operating System—Located by the saw’s handle, the electronic operating system allows the operator to see how the saw is running easily.
- Low Oil Sensor – The low oil sensor lets the operator see when the oil is low to keep the bar and chain properly lubricated.
- STIHL Quickstop® – STIHL chainsaws are equipped with a chain-stopping system to reduce the risk of injury in certain kickback situations. It is called a STIHL Quickstop® chain brake. The STIHL Quickstop® chain brake is designed to stop the chain’s rotation if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quickstop® chain brake can be activated by inertia, stopping the chain within fractions of a second.
- IPX4 Rating – This tool is IPX4-rated for weather-resistant construction and has been designed and tested for splash-water protection.
- Ematic™ Lubrication System – The Ematic™ guide bar, when used with STIHL OILOMATIC® saw chain, will provide proper lubrication and less oil consumption than conventional methods. The system works because two ramps, strategically placed in the guide bar rail, help contain the flow of oil and direct all lubrication to the sliding faces of the bar and chain links as well as the rivets and driver holes, which in turn can reduce bar oil consumption up to 50%.
- STIHL Electric Motor – Lightweight and compact, STIHL electric motors require minimal maintenance and feature low noise levels and reduced vibration.
Magnesium Motor Housing – Magnesium motor housing adds durability to this powerful chainsaw.
- AGZA Certified – Meets the low-emission standards established by the American Green Zone Alliance.
- Captive Bar Nut—The captive bar nut is held securely, eliminating the risk of dropping or losing it during saw chain maintenance.
- Lightweight Portability – This product is lightweight for easy portability, excellent maneuverability, and extended use.
- Rubberized Soft-Touch Handle—The soft rubber texture is easy to grip and makes the product comfortable to hold for extended periods.
- Anti-Vibration System—STIHL has developed a system for minimizing the vibration levels of handheld outdoor power equipment. The system helps reduce operator fatigue and provides a more comfortable working experience.
- Side-Access Chain Tensioner – The side-access chain tensioner makes it much more convenient for the user to adjust the saw chain with a bar wrench as opposed to the typical location of the guide bar adjustment screw.
- Throttle Trigger Interlock – This safety feature must be depressed before the trigger can be activated.
- Reduced-Emission Engine Technology—Caring for Nature—The STIHL Inc. “Caring for Nature” seal identifies its powered products as more environmentally conscious, producing zero or low exhaust emissions. STIHL Inc. defines “low exhaust emissions” as cleaner than EPA and CARB exhaust emission standards.
View Our Usage Chart
MSA 300 C-O Specifications |
POWER SOURCE | Battery |
POWERHEAD WEIGHT | 9.9 lbs. |
WEIGHT (w/ AP 500 S) | 14.1 lbs. |
GUIDE BAR LENGTH (Recommended) | 16 in. |
OILOMATIC® CHAIN | .325 RS3 |
CHAIN OIL CAPACITY | 10.5 oz. |
BATTERY SYSTEM | AP System |
RUN TIME (w/ AP 500 S) UP TO | 44 min. |
VOLTAGE | 36 volt |
INTENDED USE | Professional |
Note: STIHL recommends #3694 (23 RS3 67) OILOMATIC® saw chain and 16” 3003 000 3313 STIHL LIGHT 04 guide bar combination. Chainsaw weights include recommended bar and chain combination. Compatible guide bar ranges: 16" to 20". The battery working time specifications for each battery charge are estimates and may vary depending on how the tool is used and what is being cut. |
| AP 100 Black | AP 100 Orange | AP 200 | AP 300 | AP 300S | AP 500S |
Battery Charging Time (Minutes for 80% / 100% Charge) |
AL 101 Charger | 60/90 | 75/100 | 150/200 | 190/250 | 230/300 | 280/355 |
AL 301 Charger | 25/35 | 30/45 | 40/55 | 50/75 | 55/80 | 70/90 |
AL 301 4 place Charger | | | 40/55 | 50/75 | 55/80 | 70/90 |
AL 500 Charger | 25/35 | 30/45 | 30/45 | | 30/45 | 40/55 |
| AR 1000 | AR2000 | AR3000 |
Battery Charging Time (Minutes for 80% / 100% Charge) |
AL 300 Charger | 130/160 | 190/215 | 220/265 |
AL 500 Charger | 90/120 | 100/130 | 120/160 |
